格兰泰勒偏振器
|
| 材料： | a -bbo, calcite or yvo4 |
| 波长范围： | a -bbo: 200-3500 nm, calcite: 350-2300 nm, yvo4: 400-5000 nm |
| 消光比： | calcite:<5x10-5 ; a -bbo:<5x10 -6 ; yvo4:<5x10 -6 |
| 并行性： | <1 arc min |
| 表面质量： | 20-10 |
| 光束偏差： | < 3 arc minutes |
| 波前失真： | l/4@633nm |
| 损坏阈值： | >200 mw/cm2 |
| 涂层： | single layer mgf2 |
| 安装： | black anodized aluminium |
| part no. | wavelength rang(nm) | extinction ratio | angular field(°) | c.a.f a (mm) | o.d. f d (mm) | l±0.1(mm) |
| gtp6206 | 200-270(single layer mgf2)(coating@245nm) | <5x10 -5 | >6.0 | 5 | 15 | 8 |
| gtp6208 | 7 | 25.4 | 10 | |||
| gtp6210 | 9 | 25.4 | 11 | |||
| gtp6215 | 13.5 | 30 | 15 | |||
| gtp6220 | 18 | 38 | 19 | |||
| gtp6306 | 300-700(single layer mgf2)(coating@532nm) | <5x10 -5 | >6.0 | 5 | 15 | 8 |
| gtp6308 | 7 | 25.4 | 10 | |||
| gtp6310 | 9 | 25.4 | 11 | |||
| gtp6315 | 13.5 | 30 | 15 | |||
| gtp6320 | 18 | 38 | 19 | |||
| gtp6706 | 700-3000(single layer mgf2)(coating@1064nm) | <5x10-6 | >6.0 | 5 | 15 | 8 |
| gtp6708 | 7 | 25.4 | 10 | |||
| gtp6710 | 9 | 25.4 | 11 | |||
| gtp6715 | 13.5 | 30 | 15 | |||
| gtp6720 | 18 | 38 | 19 |
| part no. | wavelength rang(nm) | extinction ratio | angular field(°) | c.a. f a (mm) | o.d. f d (mm) | l±0.1(mm) |
| gtp7006 | 350-2300(single layer mgf2)(coating@1064nm) | <5x10-5 | >7.7° | 5 | 15 | 8 |
| gtp7008 | 7 | 25.4 | 10 | |||
| gtp7010 | 9 | 25.4 | 11 | |||
| gtp7015 | 13.5 | 30 | 15 | |||
| gtp7020 | 18 | 38 | 19 |
| part no. | wavelength rang(nm) | extinction ratio | angular field(°) | c.a. fa (mm) | o.d. f d (mm) | l±0.1(mm) |
| gtp8006 | 500-4000(single layer mgf2)(coating@1300nm) | <5x10-6 | <=6.5 | 5 | 15 | 7 |
| gtp8008 | 7 | 25.4 | 9 | |||
| gtp8010 | 9 | 25.4 | 10 | |||
| gtp8015 | 13.5 | 30 | 12 | |||
| gtp8020 | 18 | 38 | 15 |
