格兰汤普森偏振器
 |
 |
|
| 材料： | a -bbo, calcite | |
| 波长范围： | a -bbo: 220-1100 nm, calcite: 350-2300 nm | |
| 消光比： | calcite:<5x10 -5 ; a -bbo:<5x10 -6 |  |
| 并行性： | <1 arc min | |
| 表面质量： | 20-10 | |
| 光束偏差： | < 3 arc minutes | |
| 平面度： | l/4@633nm | |
| 损坏阈值： | >200 mw/cm 2 | |
| 涂层： | single mgf2 | |
| 安装： | black anodized aluminium | |
| part no. | l/ca | extinction ratio | angular field(°) | c.a. φ a (mm) | o.d. φ d (mm) | l±0.1(mm) |
| gmp6006 | 1.6 | <5x10 -6 | >15° | 5 | 15 | 14 |
| gmp6008 | 7 | 25.4 | 17 | |||
| gmp6010 | 9 | 25.4 | 21 | |||
| gmp6012 | 11.4 | 25.4 | 26 | |||
| gmp6015 | 13.5 | 30 | 31 | |||
| gmp6020 | 18 | 38 | 40 |
| part no. | l/ca | extinction ratio | angular field(°) | c.a. φ a (mm) | o.d. φ d (mm) | l±0.1(mm) |
| gmp7106 | 2.5 | <5x10 -6 | 14°-16° | 5 | 15 | 18 |
| gmp7108 | 7 | 25.4 | 23 | |||
| gmp7110 | 9 | 25.4 | 28 | |||
| gmp7112 | 11.4 | 25.4 | 35 | |||
| gmp7115 | 13.5 | 30 | 41 | |||
| gmp7206 | 3 | <5x10 -6 | 25°-28° | 5 | 15 | 21 |
| gmp7208 | 7 | 25.4 | 27 | |||
| gmp7210 | 9 | 25.4 | 33 | |||
| gmp7212 | 11.4 | 25.4 | 41 | |||
| gmp7215 | 13.5 | 30 | 48 |
